TP-Link ER8411 Omada VPN Router

TP-Link ER8411 Omada VPN Router

nn

Omada VPN Router with 10G Ports

nn

Features

nn

Integrated into Omada SDN

nn

Zero-Touch Provisioning (ZTP)*, Centralized Cloud Management, and Intelligent Monitoring.

nn

Centralized Management

nn

Cloud access and Omada app for ultra convenience and easy management.

nn

Quad-Core 2.2 GHz CPU

nn

Enterprise–level hardware design provides maximum performance

nn

Two 10GE SFP+ Ports

nn

1x WAN and 1x WAN/LAN 10GE SFP+ ports provide high-bandwidth aggregation connectivity.

nn

Up to 10 WAN Ports

nn

Fiber and RJ45 WAN ports with load balance raise the utilization rate of multi-line broadband.

nn

Two USB 3.0 Ports

nn

Available 4G/3G Modem connection for LTE WAN backup

nn

Highly Secure VPN

nn

Enterprise-standard SSL/ IPSec / PPTP / L2TP VPN & OpenVPN / L2TP over IPSec VPN are ideal for use across multiple branches and for WFH.

nn

Abundant Security Features

nn

Powerful Firewall, DoS defense, IP/MAC/URL filtering, and IP-MAC Binding, and One-Click ALG Activation provide world-class security.

nn

Dual Redundant Power Supplies

nn

Carrier-class reliability for enterprise networking

nn

Technical Specification

nn

Product: TP-Link ER8411 Omada VPN Router with 10G Ports

nn

Standards and Protocols

nn

n
• IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q

n

• TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP

n

nn

Interface ports

nn

n
• 2x 10GE SFP+ Ports (1 WAN, 1 WAN/LAN)

n

• 1x 1GE SFP WAN/LAN Ports

n

• 8x 1GE RJ45 WAN/LAN Ports

n

• 1x RJ45 Console Ports

n

• 2x USB Ports (Connecting 4G/3G Modem as WAN Backup)

n

nn

Network Media

nn

n
• 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m)

n

• EIA/TIA-568 100Ω STP (Max 100 m)

n

• 100BASE-TX: UTP category 5, 5e cable (Max 100 m)

n

• EIA/TIA-568 100Ω STP (Max 100 m)

n

• 1000BASE-T: UTP category 5e, 6 cable (Max 100 m)

n

nn

Fan Quantity: 2
nButton: Reset Button
nPower Supply: Redundant Dual Power Supplies (100–240 VAC, 50/60 Hz)
nFlash: 4MB SPI NOR + 256 MB NAND
nDRAM: 4 GB DDR4
nProtection: 4 kV surge protection
nEnclosure: Steel
nMounting: Rack Mountable

nn

Package Contents

nn

n
• Omada 10G Multi-WAN Security Gateway ER8411

n

• Power Cord

n

• Rack-Mount Kit

n

• Quick Installation Guide

n
